X-ray advice

During our Sarek trip in Spring 1999, we had to go through 7 airports just at the height of the Serbian war. My films were subjected to tens of x-ray controls before I got pissed and called the airport police. Indeed, the security thugs at the airports are lazy and often don't want to hand check the films. Here's some guidelines:

• Most important: Do not put films in checked luggage. The more powerful x-ray and new neutron tomography machines will destroy any kind of film. This has been confirmed by Kodak and Paris airport (among others). Damaged films show blueish stripes. Those tomographs are becoming widespread in European airports.
• X-ray for carry on luggage is OK for low sensitivity films, a couple of times (indeed my velvias passed about 10 x-rays with no damage). It is more dangerous for sensitive films (nobody knows how much more dangerous).
• So called X-ray protection bags made of lead and sold in camera stores are absolutely useless. The x-ray operator just increases the power until he sees through. Otherwise terrorists would just carry their guns in x-ray proof bags, don't you think ?
• The simplest is to just toss you films in a separate plastic bag on the X-ray belt and shut up. If it only contains films, the X-ray intensity will be very low. If you have other things in the same bag, like a metal body camera, the operator will increase the X-ray intensity until he can see through, thus exposing films to a higher dose.
• Hand inspection can be required by the passenger in the USA (see below). In other countries rules are hazy, but you can always try. In the US, if they refuse, call a cop. Tips for hand checking:

• arriving in advance and being polite helps,
• having the films out of their containers (even transparent) in advance is required,
• having some 3200 asa helps justifying the manual check (they usually know the difference),
• putting the films in advance (and in a darkroom) into plastic containers allow you to keep them in your pockets under the metal detector. Metal detectors will not harm films, nor will it harm magnetic stipes on APS films. But in case they hand inspect you, you'd better have a damn good speech ready to explain all those small cylinders taped to your body...
• big airports are the worst (Paris and Chicago are named most often for refusal of hand inspection).
• in the USA keep a copy of the following with you, just in case:

Note: This document contains FAR Part 108 including Amendment 108-17 as published in the Federal Register on September 24, 1998.

PART 108 — AIRPLANE OPERATOR SECURITY

Sec. 108.17 Use of X-ray systems.

(e) No certificate holder may use an X-ray system to inspect carry-on or checked articles unless a sign is posted in a conspicuous place at the screening station and on the X-ray system which notifies passengers that such items are being inspected by an X-ray and advises them to remove all X-ray, scientific, and high-speed film from carry-on and checked articles before inspection. This sign shall also advise passengers that they may request that an inspection be made of their photographic equipment and film packages without exposure to an X-ray system. If the X-ray system exposes any carry-on or checked articles to more than 1 milliroentgen during the inspection, the certificate holder shall post a sign which advises passengers to remove film of all kinds from their articles before inspection. If requested by passengers, their photographic equipment and film packages shall be inspected without exposure to an X-ray system.

[Doc. No. 108, 46 FR 3786, Jan. 15, 1981, as amended by Amdt. 108-1, 50 FR 25656, June 20, 1985; Doc. No. 26522, Amdt. Nos. 107-6 and 108-10, 56 FR 41425, Aug. 20, 1991; Doc. No. 26268, Amdt. No. 108-11, 56 FR 48373, Sept. 24, 1991]

What does X-ray damage looks like ?

Depends if it's a classic X-ray or a tomograph machine. The first one is equivalent to a low intensity exposure of the film, so the dark areas on your pictures are lighter, with some washed out background color (most likely the back becomes dark blue). The latter one looks like a colorful sine wave very visible on the uncut roll, depending on the angle of the film when it went through the machine.
